1940nm Medical Aesthetic Laser System for Vascular Treatment and Skin Tightening
1940nm Medical Aesthetic Laser System for Vascular Treatment and Skin Tightening
1940nm Medical Aesthetic Laser System for Vascular Treatment and Skin Tightening
1940nm Medical Aesthetic Laser System for Vascular Treatment and Skin Tightening
1940nm Medical Aesthetic Laser System for Vascular Treatment and Skin Tightening
1 / 5
1940nm Medical Aesthetic Laser System for Vascular Treatment and Skin Tightening
1940nm Medical Aesthetic Laser System for Vascular Treatment and Skin Tightening
1940nm Medical Aesthetic Laser System for Vascular Treatment and Skin Tightening
1940nm Medical Aesthetic Laser System for Vascular Treatment and Skin Tightening
1940nm Medical Aesthetic Laser System for Vascular Treatment and Skin Tightening

1940nm Medical Aesthetic Laser System for Vascular Treatment and Skin Tightening

Customization: Available
Type: 1940nm Laser
Theory: Laser
Send Inquiry

Product Description

Basic Specifications

Model NO.
GMS- 1940nm EVLT
Application
Salon, Medical Centers
Technology
Fiber Output Laser System
Product Name
1940nm Vascular Laser Equipment
Laser Wavelength
1940nm + 635nm (Aiming Beam)
Output Power
8W / 12W / 15W
Output Mode
Pulse / Continuous
Cooling System
Air Cooling
Interface
12.0-Inch Touch Screen
Dimensions
450 × 320 × 260 mm

Product Overview

1940nm Medical Aesthetic Laser System: An advanced minimally invasive solution designed for precise vascular treatment and aesthetic skin improvement. By utilizing a water-specific absorption wavelength, the system enables efficient vein closure with enhanced safety and comfort.

1940nm Medical Aesthetic Laser System

Water-Specific Absorption Mechanism

The 1940nm wavelength corresponds precisely to the peak absorption coefficient of water molecules in biological tissue. Unlike traditional wavelengths that target hemoglobin, the 1940nm laser interacts directly with intracellular and extracellular water.

  • Rapid Energy Absorption: Energy is confined precisely to the target area.
  • Localized Thermal Action: Heat is generated at the vessel wall, reducing dispersion in circulating blood.
  • Selective Photothermal Effect: Ensures reliable closure without explosive boiling or vessel rupture.

Three-Phase Biological Response

Phase 1: Activation
Selective water absorption raises local temperature to therapeutic thresholds.

Phase 2: Coagulation
Vessel wall dehydration and immediate structural protein denaturation.

Phase 3: Clearance
Treated vessels transform into fibrous cords and are naturally metabolized.

Clinical Advantages

  • Virtually Bruise-Free: Minimal red blood cell leakage due to water-targeting technology.
  • Low Hyperpigmentation Risk: Confined thermal action protects surrounding tissue.
  • Skin Tightening: Promotes collagen contraction and dermal remodeling.
  • Enhanced Comfort: Reduced nerve stimulation and shorter recovery times.

Technical Parameters

Parameter Specification Details
Laser Wavelength1940nm + 635nm
Power Options8W / 12W / 15W
Pulse Width15ms - 60ms
Frequency1 - 9Hz
Fiber TypeFiber-optic coupling (≥200μm)
Input VoltageAC 100-240V, 50/60Hz
Net Weight15 kg
Gross Weight20 kg

Detailed Photos

Laser System Detail
Application Detail 1 Application Detail 2 Application Detail 3

Safety & Precautions

  • Professional training is required before clinical operation.
  • Proper eye protection must be worn by all personnel in the treatment room.
  • Avoid treatment on active skin infections or inflamed areas.
  • Contraindicated for patients with severe coagulation disorders or pregnancy.

Frequently Asked Questions

Why is 1940nm superior for vascular treatment?
The 1940nm wavelength targets water rather than hemoglobin. This allows for more precise energy absorption at the vessel wall, minimizing the risk of vessel rupture and post-treatment bruising.
Does this laser provide skin tightening?
Yes. The controlled thermal stimulation from the 1940nm laser promotes collagen contraction and remodeling in the dermis, improving skin firmness simultaneously.
What is the recovery time after treatment?
Because the energy delivery is highly precise and localized, patient discomfort is reduced and recovery time is significantly shorter compared to traditional vascular lasers.
Can it treat spider veins on the face?
Yes, the 1940nm system is suitable for superficial vascular lesions, including spider veins on both the face and body.
Is the operation interface easy to use?
The system features a 12.0-inch intuitive touch screen that allows for easy adjustment of parameters like pulse width, frequency, and output power.
What safety measures are built into the device?
The device includes a 635nm aiming beam for precise targeting and an air-cooling system to ensure stable operation of the high-stability laser source.
